General

CPU-Socket

Intel 1700

Chipset

Intel B760

Form factor

Mini ITX

Memory

Memory Type

DDR5

Channel Supported

Dual Channel

Radio frequency min

4 800 MHz

Memory frequency (OC)

7 600 MHz

Memory slots

2 pcs.

Max Memory Supported

64 GB

Expansion Slots

PCIe generation

PCIe 5.0

PCIe x16

1 pcs.

Storage Devices

M.2 slots

2 pcs.

M.2 support

2242/2260/2280

M.2 generation

PCIe 4.0 x4

M.2 interface

PCIE 4.0 x4 and SATA modes

SATA ports

4 pcs.

Communications

Wi-Fi

Kyllä

Wi-Fi standard

Wi-Fi 6E

Bluetooth

Kyllä

Bluetooth standard

5.3

LAN controller

Intel®

LAN Speed

2.5Gb Ethernet

Internal I/O Connectors

RGB

Kyllä

Fan Connector (4-pin)

3 pcs.

Rear Panel Ports

USB type-A

Kyllä

USB type-C

Kyllä

HDMI

Kyllä

DisplayPort

Kyllä

AUX out

Kyllä

Ethernet (RJ-45)

Kyllä

Mitat ja Paino

Width

170 mm

Length

170 mm

Weight

1 kg

Paketin tiedot

Paketin mitat

236 x 190 x 101 mm

Paketin paino

1,19 kg

Paketin tiedot kpl

Paketin mitat

400 x 400 x 500 mm

Paketin paino

10,00 kg
